1200℃ Electric Resistance Furnace
- 2025-03-26 00:54
- Brother Furnace
An international university has expanded its materials science research capabilities with the acquisition of a 1200°C electric resistance furnace. The high-temperature furnace, procured by the university’s advanced engineering laboratory, will enable precise thermal processing of metals, ceramics, and composite materials. Equipped with programmable temperature profiles and advanced safety features, the furnace supports experiments in additive manufacturing, alloy development, and high-temperature material behavior analysis.
1200℃ Electric Resistance Furnace Features
- Max. Temperature: 1200°C
- Chamber Size: 500x500x500mm (WxHxD)
- Furnace chamber: High-purity ceramic fiber board.
- Heating Elements: High-quality heating wires
- Temperature Control: PID auto control with accuracy of ±1°C
- Thermocouple K type (Pt-Rh) with 99.7% purity Alumina tube
- PID auto control with 50 segments programmable
- Safety Features: Over-temperature protection, door safety switch
- Furnace top reinforcement
1200℃ Electric Resistance Furnace Technical Parameters
Model | Max. Temp (℃) | Working Temp (℃ ) | Chamber Size (W*H"D) mm | Volume (L) | Power | Phase | Themo |
|---|---|---|---|---|---|---|---|
BR-12N-1 | 1200 | 1100 | 100*100*100 | 1 | 0.8 | 1 | K |
BR-12N-2 | 1200 | 1100 | 120*120*130 | 2 | 1.2 | 1 | K |
BR-12N-3 | 1200 | 1100 | 150*150*150 | 3 | 2.5 | 1 | K |
BR-12N-5 | 1200 | 1100 | 150*150*200 | 5 | 3 | 1 | K |
BR-12N-8 | 1200 | 1100 | 200*200*200 | 8 | 5 | 1 | K |
BR-12N-12 | 1200 | 1100 | 200*200*300 | 12 | 6 | 1 | K |
BR-12N-27 | 1200 | 1100 | 300*300*300 | 27 | 8 | 1 | K |
BR-12N-36 | 1200 | 1100 | 300*300*400 | 36 | 10 | 3 | K |
BR-12N-64 | 1200 | 1100 | 400*400*400 | 64 | 16 | 3 | K |
BR-12N-125 | 1200 | 1100 | 500*500*500 | 125 | 25 | 3 | K |
BR-12N-216 | 1200 | 1100 | 600*600*600 | 216 | 36 | 3 | K |
BR-12N-512 | 1200 | 1100 | 800*800*800 | 512 | 64 | 3 | K |
BR-12N-729 | 1200 | 1100 | 900*900*900 | 729 | 80 | 3 | K |
BR-12N-1000 | 1200 | 1100 | 1000*1000*1000 | 1000 | 100 | 3 | K |
* Other size can be customized.
