Industrial Box Furnace 1200 Degree for Ceramic
- 2025-02-24 22:40
- Brother Furnace
A 1200°C Industrial Box Furnace is now ready for overseas shipment. Designed for precision control and durability, this industrial-grade furnace is engineered to meet the rigorous demands of ceramic heat treatment, and other high temperature sintering applications.
Industrial Box Furnace 1200 Degree Specifications
- Max. Temperature: 1200°C
- Chamber Size: 590x540x700mm (WxHxD)
- Furnace chamber: High-purity ceramic fiber board.
- Heating Elements: High-quality heating wires
- Temperature Control: PID auto control with accuracy of ±1°C
- Thermocouple K type (Pt-Rh) with 99.7% purity Alumina tube
- PID auto control with 50 segments programmable
- Safety Features: Over-temperature protection, door safety switch
- Furnace top reinforcement
1200℃ Industrial Box Furnace Technical Parameters
Model | Max. Temp (℃) | Working Temp (℃ ) | Chamber Size (W*H"D) mm | Volume (L) | Power | Phase | Themo |
|---|---|---|---|---|---|---|---|
BR-12N-1 | 1200 | 1100 | 100*100*100 | 1 | 0.8 | 1 | K |
BR-12N-2 | 1200 | 1100 | 120*120*130 | 2 | 1.2 | 1 | K |
BR-12N-3 | 1200 | 1100 | 150*150*150 | 3 | 2.5 | 1 | K |
BR-12N-5 | 1200 | 1100 | 150*150*200 | 5 | 3 | 1 | K |
BR-12N-8 | 1200 | 1100 | 200*200*200 | 8 | 5 | 1 | K |
BR-12N-12 | 1200 | 1100 | 200*200*300 | 12 | 6 | 1 | K |
BR-12N-27 | 1200 | 1100 | 300*300*300 | 27 | 8 | 1 | K |
BR-12N-36 | 1200 | 1100 | 300*300*400 | 36 | 10 | 3 | K |
BR-12N-64 | 1200 | 1100 | 400*400*400 | 64 | 16 | 3 | K |
BR-12N-125 | 1200 | 1100 | 500*500*500 | 125 | 25 | 3 | K |
BR-12N-216 | 1200 | 1100 | 600*600*600 | 216 | 36 | 3 | K |
BR-12N-512 | 1200 | 1100 | 800*800*800 | 512 | 64 | 3 | K |
BR-12N-729 | 1200 | 1100 | 900*900*900 | 729 | 80 | 3 | K |
BR-12N-1000 | 1200 | 1100 | 1000*1000*1000 | 1000 | 100 | 3 | K |
* Other size can be customized.
