W Shape Mosi2 Heating Elements , Research Molybdenum Disilicide Heating Elements

Name: W Shape Mosi2 Heating Elements , Research Molybdenum Disilicide Heating Elements
Brand: Brother Furnace
SKU: BR1700 / BR1800
Rating: 4.5 (160 reviews)

Product Details:

Place of Origin:	China
Brand Name:	Brother Furnace
Certification:	CE
Model Number:	BR1700 / BR1800

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiation
Packaging Details:	Strong wooden box for global shipping
Delivery Time:	3-21 Working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	10000 pcs per month

Contact Now

Detailed Product Description

Max Temperature:	1700°C / 1800°C	Shape:	W Shape
Diameter:	3/6, 4/9, 6/12, 7/12, 9/18, 12/24mm	Heating Zone Length:	80 - 1500
Cooling Zone Length:	80 - 1500	Molybdenum Purity:	99.9% High Purity
High Light:	molybdenum disilicide heating elements , electric heating element

W Shape MoSi2 Heating Elements, High Purity Molybdenum Disilicide Rod up to 1800°C

Application: Widely used in research and production of glass, ceramic, refractory, metallurgy, steel-making, crystal, electronic parts, semiconductor material. The model including BR1700 (working temperature 1600℃) and BR1800 (working temperature 1700℃)

W Shape Mosi2 Heating Elements , Research Molybdenum Disilicide Heating Elements 0

The heater has the function of antioxidant and auto repair, and suitable to different kinds of continuous working during the oxygen atmosphere.
Moulding by heat process and model size is standard, so we can produce special shape and size according to customer requirements.
Adopt a special process for joint moulding with fasten welding and strong impact resistance.
High density and excellent electrical conductivity, high heating rate, and low power consumption.
The old one and the new one could be using together.

W Shape High Purity MoSi2 Heating Elements up to 1800°C Technical parameter

Heating zone dia. D1	Cooling zone dia. D2	Heating zone length Le	Cooling zone length Lu	Central distance A
3mm	6mm	80-300mm	80-500mm	25mm
4mm	9mm	80-350mm	80-500mm	25mm
6mm	12mm	80-800mm	80-1000mm	25-60mm
7mm	12mm	80-800mm	80-1000mm	25-60mm
9mm	18mm	100-1200mm	100-2500mm	40-80mm
12mm	24mm	100-1500mm	100-1500mm	40-100mm
Note: 1.Special size is customizable. 2.Delivery time only need 3 days for normal size
Model: BR1700 (working temperature 1600℃) and BR1800(working temperature 1700℃)
